Omegon Apochromatic refractor Pro APO AP 121/678 Quintuplet OTA

Omegon Apochromatic refractor Pro APO AP 121/678 Quintuplet OTA

Omegon 121mm/678mm Quintuplet Apochromat, flat field and 4" focuser
Manufacturer : Omegon
SKU : Ni-65143
Price: 4990.00 € incl tax 19% (Germany)
Estimated delivery time : 3-4 days
Product description

What is it that drives astrophotographers again and again? It is the fascination of imaging the sky in its most beautiful colours and shapes. With this Quintuplet Apochromat, this succeeds wonderfully. A triplet lens with ED glass, an integrated flattner and a 4" focuser are the three strengths for successful astrophotos.

Put an end to images without contrast. The Apochromat shows what is really possible: pure colour and high contrast observations and astrophotos. The reason is a sophisticated optical design with Premium ED glass for a crystal clear image. Compared to most mirror systems, the better defined optics allow you to see more and finer details when observing planets, for example. The lens elements have been provided with an effective multi-coating against reflections on all surfaces. Look forward to observations and images that will remain in your memory.

Full-frame fans need space: this is exactly what the eyepiece focuser in gear design offers. It complements this premium optic beautifully and offers you great illumination and images without shadowing. The hybrid technology of Crayford and gear wheel makes it very smooth-running on the one hand and incredibly powerful on the other. A 1:10 reduction for the finest corrections rounds off this focuser. It is precisely these features that astrophotographers all over the world appreciate.

Object found and focused, but misaligned? At night, you should save yourself the trouble of starting all over again and aligning an elongated object to fit the sensor. The 360° rotatable extension makes this task easy, as it is done in seconds. Nothing will ever get jammed here again: the integrated thread offers you the possibility to firmly connect your accessories. For example, take your off-axis guider optimised for full-frame format and screw it in place - as if it were a permanent part of your new telescope.

The tube of the Omegon Apo consists of a CNC machined metal construction with a sophisticated aperture system against reflections. The complete tube has been lined with a velvet-like black fabric. The dew cap of the Apo can be pulled out and fixed with a screw. It can be retracted for transport.

Characteristics:

  • Triplet ED Apo lens design
  • Aperture 121mm, focal lenght 678mm, f/5.6
  • 4" focuser with 1:10 reduction
  • Integrated doublet reducer/corrector
  • Image circle 49mm
  • Modern multi coatings
  • Compact and powerful
Delivery:
  • OTA 121/678mm quintuplet ED lens
  • 4" focuser with reduction
  • M48x0,75 adapter
  • Doublet reducer/corrector inbuilt
  • 360° rotation
  • Tube rings w/ handle
  • Losmandy level dovetail
  • Vixen level finder bracket
  • Transport case
Products specifications
Coating Multicoated
Tube weight 19.38 lb incl. Tuberings
Tube material ALU / CNC produced
Type of telescope Apochromatischer Refractor
Transportation length 600 mm
Connection to eyepiece 2" / 1.25"
Focal ratio f/5.6
Aperture 121mm
Lens 5 Lences ED
Focuser 4" rack with 1:10 reduction ratio
Focal length 678mm
