Refractors

The 107PHQ is a transportable APO refractor for astrophotography with corrected field of view up to full frame sensor and for observation up to the highest magnification range.

• Aperture 107 mm - focal length 740 mm - focal ratio f/7
• 4-element Petzval system with color-correct triplet objective and a corrector lens built into the optical tube
• Stable 3.4" RAP focuser with micro-reduction and 360° rotation - adjustment range 110 mm
• Sufficient working distance for observing with 2" accessories and for photography
• Besides 1.25" and 2" the apo offers M48, M54, M68 and M86 threads for screw adaptions
• 44 mm image circle with full illumination and correction allow the use of large sensors with high resolution
• CNC tube rings with Vixen/EQ5 style dovetail bar and carrying handle
• Finder shoe for standard finder and mini guiding telescopes available
• High quality carrying case for optimal protection of the telescope
• Each Quadruplet Apo is inspected and its optics tested before shipping - you get an optimally adjusted telescope for successful photography and observation from the very beginning.

This long focal ratio flatfield apochromat support 60 mm image circle and does not need calculations for backfocus. If the image is sharp, the field is flat.

• 130 mm aperture, 1000 mm focal length, f/7.7
• Petzval like, self flattening design with two ED elements
• 3.4" dual speed focuser
• 2" and 1.25" receptacles, M68, M54 and M48 threads
• Retractable dew shield
• Losmandy style dovetail bar
• Handle
• Vixen type finder base
