The AX103S is a top class ED Apochromat in the refractor series. It has a Triplet ED lens and a field flattening lens at the rear. The f8.0 refractor has a central ED lens in the objective and reduces chromatic aberration to an absolute minimum.
The integrated field flattening lens ensures a sharp image right to the edge of the field of view, which is very important in astrophotography. An optional Focal Reducer can reduce the aperture ratio to 1:5.6 for faster results in astrophotography.
The AX103S has been specially designed for photographic purposes, but is also a real visual highlight, especially for moon and planet observation. The AX 103S is corrected up to full frame photography and delivers pin-sharp images right into the corners of the field of view.
The 60mm ring on the eyepiece extension allows you to use 2" eyepieces and a camera adapter.
This telescope will inspire you for a lifetime.
Characteristics:
- Triplet ED Apo lens design
- Aperture 103mm, focal lenght 825mm, f/8.0
- Integrated flattener lens
- Optimized for full frame astrophotography
- 60mm / 2" focuser with reduction
- Adapter 1¼"
- Optional reducer/corrector
- Tube rings and handle
- Weight appr. 4.6kgs
Delivery:
- OTA 103/825mm Triplet ED lens
- 60mm / 2" focuser with reduction
- Adapter 1¼"
- 7x50 finderscope
- Flipp mirror 1¼"
- Tube rings and handle
- Vixen level dovetail
Products specifications
| Focal ratio | f/8 |
| Limit value | 11.8mag |
| Tube weight | 14.1 lb with Tuberings |
| Included accessories | Property Value |
| Tube diameter / Length | OD=115mm, L=687mm |
| Type of telescope | 103mm ED 4-Linsen APO, multi-coated |
| Focal length | 825mm |
| Resolution | 1.13 arcsec |
