Vixen AP Photoguider

Vixen AP Photoguider

Das modulare AP Montierungs System wurde speziell für die Reiseastronomie entwickelt, lässt sich komplett zerlegen und modular erweitern
SKU : VX-X000184
Price: 1376.00 € incl tax 19% (Germany)
1529.00 €
Estimated delivery time : 3-4 days
Product description
Vixen AP Photoguider

The AP Photo Guider is a lightweight Star Tracker for long exposure times in astrophotography.
It has the same precise functions as the AP mount, but is easier to transport.

The AP Photo Guider comes with the STAR BOOK ONE controller and guarantees precise tracking during long exposure times.

It was developed in order to create razor-sharp images of the night sky with larger telephoto lenses.

The STAR BOOK ONE controller has different speeds, e.g. for the sun and the moon.
It also features backlash compensation and PEC.

The STAR BOOK ONE features an Autoguider input for precise tracking accuracy during long exposure times. The newly developed polar finder provides an easy way to achieve polar alignment. Simply line up two reference stars with the markings in the reticle. This means that no hour angle settings are required.

FEATURES

  • Motors: R.A. Motor module and STARBOOK ONE controller
  • 6 kg load (photographic)
  • Tripod: APP-TL130 tripod
  • RA /DEC: Worm gears with 140 teeth
  • RA axis: 59 mm diameter, aluminium alloy
  • DEC axis: 59 mm diameter, aluminium alloy
  • Azimuth adjustment: 1.4 degrees for each rotation over 2 setting screws
  • Latitude setting: 0-65 degrees via setting screw
  • Motor: Stepper motor

DELIVERY CONTENT
  • Vixen AP Photoguider
  • APP TL 130 tripod
  • STARBOOK ONE controller
Products specifications
Weight equatorial head 2.4Kg
