TS Optics 20 mm Plössl Eyepiece with 1.25" barrel size and 50° apparent field of viewA good Plössl eyepiece outperforms a simple Kellner. We can offer this type of eyepiece at a price for which you would get only more simple eyepieces elsewhere. Nevertheless, the features are quite impressive.
The 20 mm Plössl is a very beautiful eyepiece for deep-sky
observation, due to the good ease of view and the high contrast. It is
often chosen for binoviewers, too, as even viewers with small prisms can
illuminate the field very well.
Areas of application of Plössl eyepiecesThrough the four-element design, the Plössl is a true all-rounder. It does not introduce an additional chromatic aberration to the system, in opposite to more simple eyepieces with fewer elements. As a consequence, these eyepieces can be very well used for observing the moon and planets with higher magnifications.
At lower magnifications, Plössl eyepieces are well suited for observing nebulae, star clusters and galaxies, they convince with a field of view relatively free of distortion.
Astrophotographers can also work well with Plössl eyepieces, as they are well suited for eyepiece projection. The MgF2 coating prevents disturbing reflections and provide good contrast. However, many projection adapters are too narrow for the Plössl eyepieces with 32 or 40 mm focal length.
Delivery contents
Products specifications
Barrel size / Filter thread
|
1 1/4" with filterthread |
Coating
|
MgF2 |
Lenses / groups
|
4 / 2 |
Field of view
|
50° |
Focal length
|
20 mm |
Type of eyepiece
|
Plössl |
Eyegard
|
rubber, foldable |
