TS Optics Imaging Star 100mm f/5.8 Quadruplet Astrograph - FPL-53 Apo Objective

TS Optics Imaging Star 100mm f/5.8 Quadruplet Astrograph - FPL-53 Apo Objective

The new 100 mm f/5.8 Quadruplet Astrograph from TS.
Manufacturer : TS Optics
SKU : TSO-TSAPO100Q
Price: 2299.00 € incl tax 19% (Germany)
Estimated delivery time : 1-4 days
Product description

The 100mm f/5.8 quadruplet from the TS Imaging Star line was developed by Teleskop-Service for the demanding astrophotographer and observer. Thanks to the FPL-53 lens with air spacing, the image is free of color errors and offers excellent contrast. The field is very well flattened by the built-in corrector. You will have excellent star imaging in the field right from the start, without the hassle of finding correctors and the correct distance. Although this apo has been optimized for astrophotography, it will also perform very well visually. The stars are crisp and are shown without color errors. The image remains clean and rich in contrast up to approx. 300x.

This telescope has a classic apochromatic lens with an air space between the elements. The lens is adjustable. The cell is temperature compensated, even low temperatures do not change the star image. The main lens is FPL-53 from Ohara - Japan. Each glass-air surface has the best possible coating from the manufacturer.

The 3" CNC focuser is based on the Starlight Feather Touch ™ FTF3035 and therefore is clearly superior to conventional Crayford focusers. The power is transmitted by a helical drive rod and is decoupled from the actual bearing of the extension tube. This increases rigidity even with a maximum load (up to 6kg ).

Characteristics:

  • High quality doublet-ED primary lens
  • Integrated corrector lens with optimised space
  • Aperture 100mm, focal lenght 580mm, f/5.8
  • Multi-coatings on any glass-air surface
  • 3" R&P focuser with micro reduction
Delivery:
  • Optical tube 100/580mm
  • Dew cap, retractable
  • 3" R&P focuser with micro reduction
  • Reductions to 2", 1¼"
  • Tube rings
Products specifications
Coating Multicoated
Case Aluminium case
Viewfinder none supplied
Tube material Aluminium
Aperture 100 mm
Resolution 1.15"
Limit value 11.8mag
Max. useful visual power 200 x
Transportation length 490 mm
Color black / white
Focal ratio f/5.8
Focal length 580 mm
Backfokus 125 mm
Focuser 3" Rack and Pinion Focuser with 1:10 Micro Focusing
Tube weight 11.7 lb
Dimensions of cas 615 x 260 x 220 mm
Total weight ca. 20 lb
Connection to eyepiece M78x1, M68x1, 2", 1.25"
Type of telescope 4-Element Apo Refractor
Lens 4-Element Apo
