TTS-160 Panther Topmount, Arms
Ajustable clutch on altitude axle
The Topmount easily installs on the mount head via two conical brass bushings inserted into the ends of the altitude axle. The two lock handles works as clutches that can be released completely when balancing the telescope and locks completely when only running the mount via the motors. If wished the clutches can be set so that the mount can be moved manually and still stays in position.
3 inch dovetail saddleThe top dovetail saddle is 3 inch wide (Losmandy style) and locks securely onto the dovetail bar via two brass cylinders. The finger screws are small and compact designed to give the necessary force on the dovetail bar without taking up to much space.
Magnetic handpad holderOn each side of the Topmount is a magnetic holder for the handpad. Aditional magnetic holders can be delivered if you want to place the handpad elsewhere on the telescope.
Adjustable counterweight slotsThe Counter weight slots on each side can receive 2 counterweights.
Included Items:- Dovetail Saddle plate with counterweight arms
- 2 Magnetic handpad holders (installed on arms)
- 2 Brass bushings
- 2 M8x60 Stainless steel screws
Products specifications
Material
|
Aluminium, Steel |
Weight
|
5.1 kg |
Suitable for
|
3" Losmandy prism rails |
Dimension
|
60x25x20cm |
