Solarfilter SF100 from Euro EMC Size 103 mm - 144 mm

Solarfilter SF100 from Euro EMC Size 103 mm - 144 mm

Solarfilter Series SF100 from Euro EMC to attach on your Telescope.
SKU : EMC-SF100-5
Price: 63.00 € incl tax 19% (Germany)
70.00 €
Estimated delivery time : 1-4 days
Product description
Solarfilter SF100 from Euro EMC Size 5 (103 mm - 144 mm) to attach on your Telescope

Complete series of lens-solarfilter to attach to the frontside of your telescope
  • The filter foil is clamped plan between two aluminium rings
  • For visual and photographic using
  • Variable adjustable camping on the tube
  • Delivery including filter foil type Astro Solar (Baader Planetarium)
  • Made for all telescope types including viewfinder and binoculars except Schiefspieglers

The scure fixation of the solar filter on the front end of tube or dewcap will be done with 4 threaded columns made from Polyamid with precisely adjustable clamping. The standard sizes will normally be attached outside on the dewcap, but you can also attach iit inside with a minimum of vignetting.

The used filter foil has an excellent optical quality and is easily to change if damaged.

The standard sizes 1 and 2 are cutted to enable the using with binoculars (you need 2 pieces). The objective distance than had to be minimum 65 mm or 78 mm.

Delivery will be done completely assembled with the standard filter foil with a density of ND5 for visual and photographic use, the mounting pins are enclosed for self installation. For the focal Photography this density is perfect (e.g.: f/8, 100 ASA, t= 1/500).

The solar filter will be mounted without any seal on the front side plan to the tube or dewcap. Contrary to possible concerns with this construction you won´t have any scattered light. The contrast only will be weakened if intentionally a gap of minimum 4 mm will be done!


Delivery contains:
  • Filter Frame
  • 4 Mounting Pins
  • Filter Foil


Products specifications
Type of filterWhitelight solarfilter
ConstructionFilter Foil with Frame
DensityND5.0
Made for telescopeAll Telescopes except Schiefspielers
Aperture98 mm
Diameterfor Diameter 103 mm to 144 mm
