SkyWatcher EQ-AL55i PRO SynScan™ equatorial telescope mount

SkyWatcher EQ-AL55i PRO SynScan™ equatorial telescope mount

Computer-controlled equatorial WLAN GoTo mount for all latitudes

  • The EQ-AL55i is fully controlled via a smart device using the built-in WLAN module using the freeware "SynScan Pro App" for iOS and Androidcontrolled.
  • Application at all latitudes from 0-90 degrees

Manufacturer : Skywatcher
SKU : SKY-20859
Price: 836.00 € incl tax 19% (Germany)
929.00 €
Estimated delivery time : 3-4 days
Product description

Computer-controlled equatorial WLAN GoTo mount for all latitudes

This wonderfully versatile, new Sky-Watcher EQ-AL55i Pro is equipped with
equipped with a counterweight bar that can be adjusted in two positions allowing it to be used at all latitudes from 0-90 degrees and thus avoids the problems that arise with most other mounts at extreme polar altitudes. The EQ-AL55i is fully controlled via a smart device using the built-in WLAN module with the help of the freeware "SynScan Pro App" for iOS and Android.

The EQ-AL55i Pro mount is already equipped with a built-in, illuminated polar finder scope for precise alignment to the celestial celestial pole and includes connections for USB-C, autoguider as well as an optionally available SynScan hand control box and a control socket for triggering a DSLR (also programmable via
the SynScan Pro app)

The EQ-AL55i Pro allows a payload of up to 10kg and is equipped with a 45mm
dovetail clamp to attach a huge range of telescopes and accessories. accessories can be attached. The EQ-AL55i Pro is a great mount for mount for the astrophotographer, but also for the visual observer observer who wants a powerful mount that is easy to transport.
mount that is easy to transport. In addition, an optional 200mm tripod extension column (no. 20860), a SynScan hand control box with cable (no. cable (No. 20948/20193) and a 5kg counterweight (No. 20950) are also available.

Scope of delivery:

  • EQ-AL55i Pro mount
  • 1.75" tripod with stainless steel legs and support plate
  • 1.8kg / 3.5kg counterweights
  • SkyWatcher EQ-AL55i PRO SynScan™ equatorial telescope mount


Products specifications
Type of mount Parallactic GOTO mount
Payload max. (depending on using and demand) 10 Kg
Polar hight adjustment 0 - 90°
Motors DC Servo Motors
Motor control SynScan GoTo
Power Supply 12 V, 2 A
Tracking speeds 0.25 x, 0.5 x, 0.75 x, 1 x
Weight over all 19.5Kg incl. Counterweight
Connections USB, SNAP, Power, ST-4 & Synscan Hand Controller (optional)
Diameter of Gear / Number of Tooth R.A. Worm Gear 73.4mm Diameter, 144 Teeth, DEC Worm Gear 51.6mm Diameter, 100 Teeth
