ToupTec sMAX16AM CMOS Kamera mit 9µm Pixel
Call for pricing
Estimated delivery time : 1-2 months
ATR432C features a resolution of 1600x1100 pixels, 9 ?m pixels and a 1.1-inch optical format.It offers support for high frame rate mode(109FPS at all Pixel Readout 12 bit),and has a readout noise level as low as 2.4e. Additionally ,the camera have an excellent TEC cooling system maintains precise temperature control within a deviation of 0.1?, while the dew prevention heater (window heating) further enhances performance.
1629.00 €
Estimated delivery time : 2-4 weeks
ToupTek USB 3.0 color astro camera with powerful Sony CMOS sensor for astrophotography - with very small pixels for high resolution
Powerful two-stage Peltier cooling up to 35 °C below ambient temperature 1" sensor SONY Exmor CMOS IMX183, color back-illuminated 13.06 x 8.76 mm size, diagonal 15.9 mm 5440 x 3648 pixels - 20 MP Extremely high resolution due to 2.4 µm pixel size Connection on telescope side: M42x0.75 female thread, 2" barrel Working distance only 17.5 mm from the barrel Built-in protection windows Binning is supported
879.00 €
Estimated delivery time : 1-4 days
ToupTek USB 3.0 monochrome astro camera with powerful Sony CMOS sensor for astrophotography - with very small pixels for high resolution
Powerful two-stage Peltier cooling up to 35 °C below ambient temperature 1" sensor SONY Exmor CMOS IMX183, monochrome, back-illuminated 13.06 x 8.76 mm size, diagonal 15.9 mm 5440 x 3648 pixels - 20 MP Extremely high resolution due to 2.4 µm pixel size Connection on telescope side: M42x0.75 female thread, 2" barrel Working distance only 17.5 mm from the barrel Built-in protection windows Binning is supported
1069.00 €
Estimated delivery time : 1-4 days
Cooled USB 3.0 full frame astro camera with high sensitivity and zero-amp glow for deep sky astrophotography
Full-frame color sensor Sony IMX410 - back-illuminated 24 x 36 mm - diagonal 43.3 mm 24 MP - 6064 x 4040 pixels Pixel size 5.94 µm - can be used on almost all telescopes 14 bit ADC - dynamic range like a CCD sensor No amplifier glow due to Zero Ampglow circuitry Built-in UV/IR blocking filter as protection glass Heater installed to prevent condensation - Sensor chamber is sealed airtight 512 MB DDR3 buffer for stable data transmission M54x0.75 connection thread (female) Back focus 17.5 mm (distance sensor to thread) Binning is supported Manufacturer of the camera is Touptek
2990.00 €
Estimated delivery time : 3-4 weeks
Touptek CMOS camera SkyEye62AC/AM
Powerful CMOS camera for DeepSky photography
- Sony CMOS IMX455 chip
- Full frame format
- 60 mill. pixels
- 16 bit ADC
- 512 MB DDR3 RAM
- USB3/USB2
- Cooling -35°
- 6.3 frames/sec doenload/image at full resolution
- QE >80%
- Available as monochrome or colour version
4190.00 €
Estimated delivery time : 4 weeks
