Rowan Mount AZ75
AZ 75 - the new deluxe double-sided mount with up to 15 kg load capacity!
This elegant yet very robust azimuthal double mount is CNC machined and has been anodised black and finished with stainless steel hardware.
Features include adjustable clamps on both axes, each with 360° movement, allowing simultaneous alignment.
Movement in all directionsThe practical manual axis clamps allow you to freely align each instrument and simply fix it again when the desired position is reached. Very practical: the movement allows you to track both instruments at the same time. This means no stress and maximum comfort during observation.
Two telescopes can be attached to the outriggers in parallel.
The load capacity is 15 kg per side, depending on the telescope length !
Optional M10, M12 or 3/8" connection thread (Please specify when ordering)
Scope of delivery:
Products specifications
|
Color
|
Black |
|
Payload max. (depending on using and demand)
|
33 lb |
|
Material worm
|
Brass |
|
Material wormwheel
|
Aluminium |
|
Material
|
hard aluminum alloy |
|
Weight rating:
|
ca, 20 kg |
|
Weight equatorial head
|
4.4 Kg |
|
Tripod connection
|
M10, M12, 3/8" |
