The APM Ultra Flat Field eyepiece series is a further development in the field of field correction and viewing comfort. The performance of the newly calculated optics is astonishing in view of the great price. In particular, the details of the optics, such as high-quality FMC multi-coating and effective internal blackening of the optical and housing components, produce a high-contrast, pure-color and sharp image. Our UFL can rightly be called "little stars".
Our UFL 10mm 1.25" model is a real universal eyepiece. 10mm focal length can be used for a wide range of observation situations. The optical construction is 5 lenses in 4 groups, the AP is 16mm and is sufficient for people who wear glasses.
Characteristics:
- 1.25" diameter with integrated filter thread
- Large upper field lens for easy viewing
- Suitable for people who wear glasses
- Sharp-edged image (without distortion)
- High quality multi coatings
- Universal usable
Delivery:
- UFL eyepiece 10mm 60° 1.25"
- Dust caps
- Carton packaging
Products specifications
| Field of view | 60° |
| Coating | Multicoated |
| Barrel size / Filter thread | 1 1/4" with filterthread |
| Lenses / groups | 5 / 4 |
| Eyegard | Rubber foldable for eyeglas wearers |
| Eye relief | 16 mm |
| Focal length | 10 mm |
| Type of eyepiece | Flat Field eyepiece |
| Weight | 2.8 oz |
| Field stop | 14.7 mm |
| Height | 26mm (without barrel) |
| Diameter | Diameter eye lense 17mm |
| Connecting thread | Remove the eyepiece rubber M34x0.75-6h |
